125mm Architectural Curtain Aluminum Casement Windows
Product Details:
Place of Origin: Guangzhou,China
Brand Name: APRO,OEM
Certification: SONCAP,ISO9001
Model Number: ACW-01211522
Payment & Shipping Terms:
Minimum Order Quantity: 3 Square Meter
Price: negotiation
Packaging Details: foam layer and hard cardboard inside & wooden case outside which is suitable for container shipping.
Delivery Time: 30-40 days for 10-100M2 , if more than 100 M2 need to be negotiated
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: More than 5000 square meter per month
Contact Now
Detailed Product Description
Open Style: Swing Frame Material: Aluminum Alloy
Color: White/Black/Grey/Champagne/Wood Grain Hardware: Chinese Top Brand
Size: Customizable Size Material: Aluminium Alloy Thermal Break/Non-thermal Break
Glass Type: Low-E Glass/Reflected Glass/Tempered Glass/Float Glass/Art Glass,5-10mm Single/5+12A+5 Double Glazed,5+9A+5 Type: Casement Windows
High Light:

125mm Aluminum Casement Windows

,

Curtain Aluminum Casement Windows



Hot Sale European House type Aluminium curtain Casement Window



The Apro range of windows and doors has been designed to deliver a premium level of quality, performance, and style in architectural aluminium design.

The Apro awning/casement window features a gently curved sash profile, high-quality hardware and the option of either single or double glazing for a range of thermal performance options. The positive sealing of the Genesis Awning and Casement also ensures excellent weather sealing characteristics.



Benefits
Premium quality 80mm & 125mm architectural framing system
100mm front & centre glazed Commercial framing options
Single and double glazing options
Distinctive aesthetics, high quality hardware
High wind and water performance options
Compatible with the full range of Apro window and door suites



125mm Architectural Curtain Aluminum Casement Windows 0



If the window is left open, a lot of rain will hit the top of the sash and splash into the house, even with no wind. A good roof overhang can help a lot. In very windy weather, the wind scoop can turn into a sail and get whipped around by the wind, making a racket and potentially damaging the window. The hardware can cause trouble over time, especially with large, heavy casements. The gears that open and close the window when you operate the handle can strip. The linkage that connects the locking lever to the window locks can break. I’ve seen this happen more than a few times. The opening levers are generally easy to replace, but the locking linkage requires removing the casings to get at the guts of the window. Finally, installing a conventional window air conditioner, or a portable unit with a hose, is difficult. Typically, you’ll need to fabricate an insert to adapt the opening to the air-conditioner or hose – not a simple task.



125mm Architectural Curtain Aluminum Casement Windows 1





Pros of Double-Hungs
Easy to operate, reasonably tight (with modern, high-quality window), easy to install a portable air-conditioner. With an insert, can do a pretty good imitation of true divided lites, common on older traditional windows. Tend to stay fairly dry if left open in a moderate rainstorm. Many offer easy-to-clean tilt-in sash that allow easy access to exterior surfaces.

Cons of Double-Hung Windows
Half the ventilation capacity of a casement. The meeting rail obstructs views.
Over time, the sash cords and vinyl jamb liners can deteriorate and the movable sash may not stay in the raised position. The sash cords are tensioned and can be tricky to replace.

Vinyl vs. Vinyl-Clad
Solid vinyl windows have come a long way since their introduction in the 1979s. They were originally used only for replacement windows, but were gradually accepted in the new home market. There is a wide range in quality from “builder-grade” windows to premium products. The best ones are reinforced at all their stress points so maintain good dimensional stability.



125mm Architectural Curtain Aluminum Casement Windows 2



A casement is a window that is attached to its frame by one or more hinges at the side. They are used singly or in pairs within a common frame, in which case they are hinged on the outside. Casement windows are often held open using a casement stay. Windows hinged at the top are referred to as awning windows, and ones hinged at the bottom are called hoppers.





Casement windows, including awning and hopper types, "generally have lower air leakage rates than sliding windows because the sash closes by pressing against the frame.

Casement windows are also excellent for natural ventilation strategies, especially in hot climates. Casements allow more control of ventilation than flush-opening windows. They can be hinged to open outward and angled in order to direct breezes into the building.



125mm Architectural Curtain Aluminum Casement Windows 3



Product Data
Aluminium Profiles
Aluminium Alloy
ALU Wall Thickness
Surface Finishing and Color
6063-T5
1.2mm--2.0mm, Normally 1.4mm for window, 2.0mm for door
Anodized, Sliver & Bronze
Powder Coating, colore should be confirm with buyer
Electrophoresis, Sliver& Champagne
PVDF
With thermal break aluminium system design for more energy saving function
Glass
Type
Thickness
Color
Float glass
Single: 4mm -12mm, Double Glazing (With 6A/9A/12A/27A space)
clear/super clear/ tinted blue/green/coffee brown/grey
Insulated double glass
Insulated triple glass
Reflective glass
Low-E glass
Tempered glass
Laminated glass
Customized art glass
Hardware
High quality, made in China of well-know brand (Kinlong )/ made in Germany (Siegenia /Roto )
Accessories
Use EPDM sealant rubber
Stainless steel 304# accessories.
Production standard
Basis on the shop drawings which approved by the buyer
